HBTLS601 is a low capacity parallel beam single point load cell widely used device for weight measurement and force sensor. Provide high precise measurements and ease of installation, making it suitable for the pricing scale, counting scale, platform scales, vending machine and smart weighing applications.
Low Capacity: Accurately measures weights up to 3-120kg
Compact Size: Dimensions of approximately 130mm in length, suitable for integration in space-constrained applications.
Aluminum alloy construction: Raw materials can be customized according to customer requirements
IP66 Protection Rating: The load cell is designed with an IP66 rating.
Accuracy: Provides high-precision measurements suitable for applications requiring accurate weight data.
Easy installation.
Weighing Scales: Used in Low profile platforms,Bench scales, retail scales, pricing scales, counting scales and weight measurement.
Commercial Scales: Commonly used in retail and supermarket electronic scales to help merchants weigh products accurately.
Industrial Weighing: Great for warehouse, logistics, and production line weighing systems to make sure goods and materials are measured accurately.
Medical Devices: Comes in handy for medical equipment that needs weight monitoring, like patient scales or when mixing medicines.
Food Industry: Helps ensure food products weigh what they’re supposed to during processing and packaging.
Intelligent Smart Products: various of smart vending machines or smart medical or household products.
Wire Length.
Load Cell Outer Size.
Connect Connector, Example: JST or XX Brand Connetctor.
ODM/OEM.
Weighing Accessories: Amplifier, Digital Signal RS232 or RS485, Junction Boxes.
Pacakge.
| Rated Capacities | Temperature Effect On Output |
| 3-120kg | 2.0%R.O./10℃ |
| Rated Output | Temperature Effect On Zero |
| 2.0±0.2mv/v | 2.0 %R.O./10℃ |
| Zero Balance | Input Impedance |
| ±0.0200 mV/V | 410±10 Ω |
| Non-linearity | Output Impedance |
| 0.02 %FS. | 350±5 Ω |
| Hysteresis | Insulation Impedance |
| 0.02 %FS. | ≥5000 MΩ |
| Repeatability | Recommended Excitation |
| 0.02 %FS | 5~12VDC |
| 3mins Creep | Maximum Excitation |
| 0.1 %FS/3MIN | 15VDC |
| 30mins Return | OperatingTemperatureRange |
| 0.02 %R.O. | -20~60 ℃ |
| Safe Overload | Construction |
| 120 %R.O. | Aluminum Alloy |
| Ultimate Overload | Protection Class |
| 150%R.O. | IP65 |
| Cable:RED (+) BLACK(-) GREEN(+) WIHTE(-) | φ 4X2m |
| Recommended Platform Size | 350x350mm |
| Red（EXC+）,Black（EXC-）, Green（SIG+）,White（SIG-） |
As the best quality load cell sensor products manufacturer, we can provide professional solutions for any custom request. Please feel free to contact us now and we will contact you soonest.
Haibo is a large manufacturer of Various Load Cells. We design and manufacture a wide range of and high precision Class C3 and competitive prices, Single point load cells, shear beam load cells, micro load cells, truck scales load cells, Weighing alex pads, pressure sensors, torque sensors, etc.
Contact us right now to get more information, we will have people reply within 12 hours.
You can get a price of this model or send us any question to get any information you would like to know, we will reply to you soonest.
