The HaiboSensor HBTLSF3011 is a tension S beam type force compression load cell sensor that features strong corrosion resistance, making it ideal for harsh environments with IP65-IP66 protection. With low capacities ranging from 1 to 200 kN, this S-type load cell uses advanced metal foil strain gauge technology for reliable performance.
Small Capacity: Accurately measures weights up to 0.05 to 200 kN,
Aluminum alloy or stainless steel construction: We can tailor raw materials to meet customer needs.
Protection Rating: The load cell is designed to meet an IP65/IP66 protection rating.
Accuracy: Provides high-precision measurements suitable for applications requiring accurate weight data.
Easy installation.
Hopper scales & silo weighing
Crane scales & overload monitoring
Tension control (e.g., cables, ropes, conveyors)
Machine testing & force measurement
Batching, blending & mixing systems
Belt scales & dynamic weighing
Industrial automation & process control
Material testing machines
Marine/offshore equipment
Aerospace component testing
| 参数 (Parameter) | 可选范围/说明 (Options/Description) |
|---|---|
| 额定载荷 (Rated Load) | 0.5-1.5t Higher ranges customizable) |
| 输出灵敏度 (Sensitivity) | 标准范围：2.0mV/V，可调整 (Default 2.0mV/V, adjustable) |
| 电缆长度 (Cable Length) | 标准线长是2米，可定制长度 (Standard 2m, customizable length) |
| 电缆材质 (Cable Material) | PVC/ PUR/耐高温/防水等 (PVC, PUR, High-temp, Waterproof, etc.) |
| 连接方式 (Connection) | 电缆直出/航空插头 (Integrated cable/Quick connector) |
| 防护等级 (IP Rating) | IP65/IP66（防尘防水定制）(Dust/Waterproof customization) |
| 材质 (Material) | 合金钢/不锈钢 (Alloy Steel/Stainless Steel) |
| 安装螺纹 (Thread Type) | 公制/英制螺纹 (Metric/Imperial thread) |
| 工作温度 (Temperature) | -20℃~+65℃ |
HBTLSF3011 Typical Custom Requests：
Corrosion-resistant
Output Signal: 模拟信号Analog output: 4-20mA/0-10V)数字信号 (Digital output: RS485/CAN总线)
Dimensional adjustments
Custom threaded holes
Provide detailed requirements for customization：如果您需要定制S Beam Load Sensor, 需提供具体参数或应用场景。
Let me know if you need further details：如果您如需进一步细化，请告知具体需求！
| 参数名称 (Parameter) | 值/范围/描述 (Value/Range/Description) |
|---|---|
| 额定载荷 (Rated Load) (kN) | 0.5，1，1.5(kN) |
| 综合精度 (Comprehensive Precision) | 0.3%F·S |
| 灵敏度 (Sensitivity) | 2.0 mV/V |
| 蠕变 (Creep) | ±0.05 %F·S/30min |
| 零点输出 (Zero Output) | ±1 %F·S |
| 零点温度影响 (Temperature Effect On Zero) | ±0.02 %F·S/10℃ |
| 输出温度影响 (Temperature Effect On Output) | ±0.02 %F·S/10℃ |
| 工作温度范围 (Operating Temperature Range) | -20℃～+65℃ |
| 输入阻抗 (Input Resistance) | 380±10 Ω |
| 输出阻抗 (Output Resistance) | 350±5 Ω |
| 绝缘电阻 (Insulation Resistance) | >5000 MΩ |
| 安全过载 (Safe Load Limit) | 150% F·S |
| 供桥电压 (Bridge Voltage) (建议 Recommended) | 10V DC |
| 材质 (Material) | 合金钢 (Alloy Steel) |
| 传感器接线方式 (Load Cell Wiring) | |
| 输入+ (Input+) | 红 (Red) |
| 输入- (Input-) | 黑 (Black) |
| 输出+ (Output+) | 绿 (Green) |
| 输出- (Output-) | 白 (White) |
As the best quality load cell sensor products manufacturer, we can provide professional solutions for any custom request. Please feel free to contact us now and we will contact you soonest.
