HBPS1 It is primarily utilized for measuring oil pressure, cylinder pressure, and hydraulic pressure within the system. This device finds extensive application in various domains, including aerospace, metallurgy, petrochemicals, medicine, and other automatic control-related sectors.
Material: Stainless Steel
High Performance and Reliable
A wide measurement range
High Precision
Industrial automation & process control
Oil pressure,
cylinder pressure
hydraulic pressure within the system.
Measurement Range:0~100kPa-0~100MPa
Output Signal:
Analog Signal：4~20mA、0~5V、0~10V
Digital Signal：RS485、HART、CAN
Thread Connection:Thread: M20* 1.5G1/2 G1/4
Packing
| 参数/Parameter | 规格/数值 |
|---|---|
| 额定载荷 (Rated Load) | 100 kPa～35 MPa |
| 综合精度 (Comprehensive Precision) | 0.3～0.5%F·S |
| 输出 (Output) | 4～20 mA |
| 蠕变 (Creep) | ±0.1～0.3 %F·S/30min |
| 零点输出 (Zero Output) | ±2% F·S |
| 零点温度影响 (Temperature Effect On Zero) | ±0.1～±0.3 %F·S/10℃ |
| 输出温度影响 (Temperature Effect On Output) | ±0.1～±0.3 %F·S/10℃ |
| 工作温度 (Operating Temperature Range) | -20℃～+65℃ |
| 螺纹接口 Threaded Connection | M20×1.5或其它形式 |
| 电器连接 Circuit Connecting | 航空接插件aviation plug 或Hirschmann |
| 长期稳定性 Long Term Stability | ≤±0.3F·S/年 |
| 安全过载 (Safe Load Limit) | 150% |
| 供桥电压 (Bridge Voltage) | 10-30V DC |
| 材质 (Material) | 不锈钢（Stainless Steel） |
| 传感器接线方式 (Load Cell Connection) |
RED红线: 电源Power Supply |
