The HAIBOSENSOR HTLS201G is a spoke-type force sensor known for its low-profile design, outstanding rigidity, high precision, and strong resistance to unbalanced loads. This force sensor is widely used across various industries, including belt scales, hopper scales, storage scales, material tanks, material testing machines, robot and labor protection safety inspection equipment.
Material: Alloy Steel or Stainless Steel
Capacity Range: 50-200kg
An optional integrated standard signal output can be provided, such as 4-20 mA or 0-5 V three-wire amplifiers.
Protection Rating: Typically IP65/IP66 (dustproof & waterproof).
Temperature Compensation: Minimizes drift due to thermal variations
Hopper Scales & Silo Weighing — The HAIBOSENSOR force sensor provides reliable weight data for bulk materials in hoppers and silos, enabling precise inventory management and process control.
Crane Scales & Overload Monitoring — Integrated into crane systems, these force sensors deliver accurate weight readings and trigger alarms to prevent dangerous overload situations, enhancing operational safety.
Tension Control (e.g., cables, ropes, conveyors) — They ensure consistent and correct tension is maintained in cables, ropes, and conveyor belts, which is vital for system stability and longevity.
Machine Testing & Force Measurement — In R&D and quality assurance, HAIBOSENSOR force sensors deliver high-precision data to verify machine performance and structural integrity under various loads.
Batching, Blending & Mixing Systems — These sensors guarantee that precise amounts of ingredients are combined, which is essential for maintaining product quality and consistency in production.
Belt Scales & Dynamic Weighing — Installed on conveyor belts, HAIBOSENSOR force sensors accurately measure the flow rate and total weight of materials without interrupting the production process.
Industrial Automation & Process Control — They act as the critical touchpoint for gathering real-time force feedback, enabling automated systems to adjust and optimize operations seamlessly.
Material Testing Machines — Used in universal testing machines, the sensors provide the accurate force measurements required for determining the mechanical properties of materials.
Marine/Offshore Equipment — Designed to withstand harsh environments, these force sensors are used in mooring systems and load monitoring on vessels and offshore platforms.
Aerospace Component Testing — In the development of aerospace parts, they deliver the extreme precision and reliability needed for rigorous qualification and fatigue testing.
Robot — Mounted on robotic arms and end-effectors, the sensors provide essential force feedback, enabling robots to perform delicate assembly and interaction tasks with precision.
Wire Length.
Load Cell Outer Size
ODM/OEM.
Weighing Accessories: Amplifier, Digital Signal RS232 or RS485, Junction Boxes, Transmitter.
Package.
| 参数/Parameter | 规格/数值 |
|---|---|
| 额定载荷 (Rated Load) | 50-200kg |
| 综合精度 (Comprehensive Precision) | 0.05～0.1% F·S |
| 灵敏度 (Sensitivity) | 2.0 mV/V |
| 蠕变 (Creep) | ±0.05% F·S/30 |
| 零点输出 (Zero Output) | ±1% F·S |
| 零点温度影响 (Temperature Effect On Zero) | ±0.05% F·S/10℃ |
| 输出温度影响 (Temperature Effect On Output) | ±0.05% F·S/10℃ |
| 工作温度 (Operating Temperature Range) | -20℃～+65℃ |
| 输入阻抗 (Input Resistance) | 380±10 Ω or 750±15 |
| 输出阻抗 (Output Resistance) | 350±3 Ω or 700±5 |
| 绝缘电阻 (Insulation Resistance) | ≥5000 MΩ |
| 安全过载 (Safe Load Limit) | 150% F·S |
| 供桥电压 (Bridge Voltage) | 建议 10V DC |
| 材质 (Material) | 合金钢（Alloy Steel）or不锈钢（Stainless Steel） |
| 传感器接线方式 (Load Cell Connection) | 输入+: 红 (Input+: Red) 输入-: 黑 (Input-: Black) 输出+: 绿 (Output+: Green) 输出-: 白 (Output-: White) |
| 变送器接线方式 (Amplifier Connection) | 电源: 红 (Power: Red) 公共端: 蓝 (Public: Blue) 输出: 白 (Output: White) |
